RB series SR

Name: RB series SR
Brand: Salvatore Robuschi
SKU: RB serie SR
Availability: InStock

The RB series from Salvatore Robuschi comprises centrifugal pumps with a closed multi-channel impeller, manufactured in accordance with EN ISO 5199. The series offers excellent performance when pumping liquids containing solid particles, high-viscosity liquids and under critical suction conditions. Thanks to the large inlet opening and the limited number of impeller blades, the RB series also delivers excellent suction performance in the presence of dissolved gas or air.

Executions

RBB – Independent frame with oil lubrication, ideal for heavy-duty applications
RBL – Lantern bracket with flexible coupling and standard B5 motor
RBM – Monoblock with standard B5 electric motor, compact and easy to install

Expert advice

Request a quote

Specifications

Technical specifications

Product

RB serie SR

Impeller type

Channel

Maximum capacity

3,100 m³/h

Maximum head

70 mwc

Maximum working pressure

10 Bar

Maximum temperature

220°C

Brand

Salvatore Robuschi

Application

Waste incineration & flue gas treatment, Wastewater, Chemical industry, Industrial installations, Pulp and paper industry, Refinery, Textile industry, Food industry, Water treatment

Materials

Construction materials

Standard materials

Cast iron
Stainless steel 316
Superduplex (sizes 80–125)
On request: AISI 904L

Flange standard
EN 1092 PN10
On request: ANSI B16.5 150

Want to find out more about this product?

Catalogue RB-RE series SR

Range

RBB, independent frame with oil-lubricated bearings / bare shaft: RBB 65-20, RBB 80-20, RBB 80-25, RBB 80-31, RBB 100-25, RBB 125-25, RBB 125-31, RBB 125-40, RBB 150-31, RBB 150-35, RBB 200-35, RBB 200-45, RBB 250-35, RBB 250-45, RBB 300-45, RBB 400-60

RBL, lantern bracket with flexible coupling (Bi-Block): RBL 65-20, RBL 80-20, RBL 80-25, RBL 80-31, RBL 100-25, RBL 125-25, RBL 125-31, RBL 125-40, RBL 150-31

RBM, close-coupled (monoblock): RBM 65-20, RBM 80-20, RBM 80-25, RBM 80-31, RBM 100-25, RBM 125-25, RBM 125-31, RBM 125-40, RBM 150-31, RBM 150-35, RBM 200-35, RBM 200-45, RBM 250-35, RBM 250-45, RBM 300-45, RBM 400-60
