RD series SR

Name: RD series SR
Brand: Salvatore Robuschi
SKU: RD serie SR
Availability: InStock

The RD series are horizontal centrifugal pumps designed for demanding process industry applications. Designed in accordance with EN ISO 2858 and EN ISO 5199, the RD series combines high hydraulic efficiency with exceptional modular flexibility. The RD series is suitable for clean liquids free from solid particles

Executions

RDB – Independent frame with oil lubrication, ideal for heavy-duty applications
RDL – Lantern bracket with flexible coupling and standard B5 motor
RDM – Monoblock with standard B5 electric motor, compact and easy to install

Expert advice

Request a quote

Specifications

Technical specifications

Product

RD serie SR

Impeller type

Closed

Maximum capacity

500 m³/h

Maximum head

140 mwc

Maximum working pressure

16 bar

Maximum temperature

220°C

Brand

Salvatore Robuschi

Application

Waste incineration & flue gas treatment, Wastewater, Chemical industry, Industrial installations, Refinery, Textile industry, Food industry, Water treatment

Materials

Construction materials

Standard materials

Stainless steel 316
Superduplex (grades 32–80)
On request: AISI 904L

Flange standard
EN 1092 PN16
On request: ANSI B16.5 150

Want to find out more about this product?

Catalogue RD-RG series SR

Range

RDB, independent frame with oil-lubricated bearings / bare shaft: RDB 32-12, RDB 32-16, RDB 32-20, RDB 40-12, RDB 40-16, RDB 40-20, RDB 50-12, RDB 50-16, RDB 50-20, RDB 50-25, RDB 65-16, RDB 65-20, RDB 65-25, RDB 65-31, RDB 80-16, RDB 80-20, RDB 80-25, RDB 80-31, RDB 100-20, RDB 100-25, RDB 100-31, RDB 100-40, RDB 125-25, RDB 125-31, RDB 125-40

RDL, lantern bracket with flexible coupling (Bi-Block): RDL 32-12, RDL 32-16, RDL 32-20, RDL 40-12, RDL 40-16, RDL 40-20, RDL 50-12, RDL 50-16, RDL 50-20, RDL 50-25, RDL 65-16, RDL 65-20, RDL 65-25, RDL 65-31, RDL 80-16, RDL 80-20, RDL 80-25, RDL 80-31, RDL 100-20, RDL 100-25, RDL 100-31, RDL 100-40, RDL 125-25, RDL 125-31, RDL 125-40

RDM, close-coupled (monoblock): RDM 32-12, RDM 32-16, RDM 32-20, RDM 40-12, RDM 40-16, RDM 40-20, RDM 50-12, RDM 50-16, RDM 50-20, RDM 50-25, RDM 65-16, RDM 65-20, RDM 65-25, RDM 65-31, RDM 80-16, RDM 80-20, RDM 80-25, RDM 80-31, RDM 100-20, RDM 100-25, RDM 100-31, RDM 100-40, RDM 125-25, RDM 125-31, RDM 125-40
